The #solarbracket system with FRP Walkway and cable tray was installed in Indonesia with a total capacity of 1.2MW. Our roof #solarKlipLokmounting kits and FRP grating walkway are suitable for all rooftops; the fixed Klip Lok clamps depend on the type of metal roof, with either L feet set or a Klip Lok bracket.
Project: Rooftop Solar PV Plant
Location: Indonesia (Tropical Climate)
Total Capacity: 1.2 MW (Megawatts)
Solar mounting system kits: Integrated FRP (Fiber Reinforced Plastic) Walkway and Cable Tray within the Solar Bracket System.
- The Solar Bracket System
Function: The solar Klip Lok clamps, L feet, Aluminum rail, mid clamp and end clamps kits that securely anchors the solar panels to the roof.
Indonesia-Specific Adaptations:
High Wind Load Rating: Designed to withstand tropical storms and monsoon winds.
Corrosion Resistance: Aluminum with advanced coatings to combat high humidity, salt air (if coastal), and frequent rain.
- The Integrated FRP Walkway (The Safety & Access Feature)
Material – FRP (Fiber Reinforced Plastic):
Non-Corrosive: Impervious to rust, ideal for humid environments. Outperforms steel in corrosion resistance.
Non-Conductive: Enhances electrical safety for maintenance personnel.
High Strength-to-Weight Ratio: Strong yet lightweight, adding less dead load to the roof structure.
Purpose:
Provides safe, designated pathways for O&M staff to inspect, clean, and service the array without stepping on panels or roof surfaces (preventing panel micro-cracks and roof damage).
- The Integrated Cable Tray (The Organized & Protected Wiring)
Function: A dedicated, enclosed channel that neatly routes and protects the DC strings cables, AC wiring, and data communication lines from the panels to the inverters/combiner boxes.
Benefits:
Protection: Shields cables from UV radiation, physical damage, bird pecking, and rodent bites.
Safety: Contains all wiring, reducing trip hazards and electrical risks.
Aesthetics & Professionalism: Creates an exceptionally clean, engineered appearance.
Ease of Installation & Tracing: Significantly speeds up installation and simplifies future troubleshooting
The installation of a 1.2MW solar bracket system with integrated FRP walkway and cable tray in Indonesia is a benchmark for high-quality, sustainable, and safety-focused solar engineering in Southeast Asia. It addresses the core challenges of the local environment while optimizing for long-term performance and cost savings, setting a strong example for future large-scale projects in the region.
If you need the solar bracket kit or another structure, please contact us here.
